Industrial & IoT

Imber Smart

Mid-range industrial router

Product Highlights

  •    Dual SIM LTE
  •   SCADA (Modbus, IEC-101/102, IEC-104 gateway)
  •   WiFi IEEE 802.11b/g/n: AP or Client
  •   GPS (optional)
  •   Reduced size: 106 x 106 x 40 mm
  •   Temp. extended range: -40Cº to +75Cº
  •   Easy to use and easy maintenance

    • Introduction

    Imber Series  is the new Teldat's communications platform focused on providing WLAN connectivity for Smart City, and Industrial environments. With features that are especially important for this sector such as robustness, extended temperature range, connectivity via serial, digital port or ethernet interfaces which includes all the specific communication protocols.

    Competitive Advantages

    Multiple interfaces
    Serial RS-232 and RS-458, GPIO PINs, 4 ethernet ports WAN and LAN, celular and WiFi interfaces.
    Cost effective
    All round high performance router with a cost effective price.
    Easy Set-Up
    DIN-Rail included.
    Multiple range power supply
    The device has an input voltage range 9 to 48 VDC.

    Description

    Imber Smart is the perfect solution for difficult scenarios that requires specific communication interfaces. The needs of industrial environments, can be quite different from typical office or home network environments, some of the challenges that industrial routers need to face are related with the harsh environments, like extended range of temperature or humidity protection, also compatibility, which defines the capacity of having several comunitacion interfaces and protocols to ensure the data transmission between all the parts involved in the grid, remote management to be easily manageable from a central location or the cost, that needs provide value for money by being highly reliable, secure, and easy to manage.
    borrar

    Key Features

    1 x WAN + 3 x LAN or 4 x LAN
    Auto 10/100 Mbps to stablize multiple LAN and WAN comunications.
    2 x SIM slots
    Access point (AP) and client modes.

    Wireless Security WPA WPA2 WEP 64/128 AES TKIP.

    RP-SMA antenna connectors.

    Serial Port 1 x RS-232 (3 PIN) + 1 x RS-485
    Serial comunications in RS-232 and RS-485 procotols using 4 PIN of the terminal block (included with the device).
    Web GUI
    User friendly monitoring and management thu web GUI.
    DIN-rail mounting
    Standard mouting for industrial installations.
    4G (LTE) Bands
    EMEA: B1/B3/B5/B7/B8/B20, B38/B40/B41

    AU&NZ: B1/B2/B3/B4/B5/B7/B28, B40

    America: B2/B4/B12/B13

    WCDMA: B1/B2/B4/B5/B8/B19

    TD-SCDMA: B34/B39

    GSM/EDGE: B2/B3/B5/B8

    WiFi IEEE 802.11b/g/n Access Point (AP) Client
    2 x SIM slots 1.8V / 3V.

    SIM failover backup in auto-switch cases as weak signal data or connection fail.

    Digital Input and Output 2 x DI + 2 x DO
    GPIO digital input & outputs using the other 4 PIN of the terminal block.
    IP30
    Ingress protection IP30 for industrial enviroments built in 300g metal housing.
    Extended temperature range
    Operating Temperature -40 °C to 75º.
