Imber 5G is Teldat’s industrial communications platform designed to boost connectivity in Smart City and industrial environments, combining reliability, security and operational simplicity. Its compact and robust design enables 24x7 communications in remote locations.
It integrates advanced functions to connect devices and automation systems, offering SCADA capabilities and reinforced security to protect critical infrastructure. Its integration with Teldat Cloud Net Manager provides centralized control that streamlines large‑scale deployments and significantly reduces operational and maintenance costs.
The combination of 5G, Ethernet, Wi-Fi and digital I/O connectivity provides flexibility and reliable communications for deployments in industrial environments.
Adaptable hardware design for unattended installations, with extended temperature range (-30ºC a 70ºC) and electrical/electromagnetic immunity.
Easy installation thanks to its compact design, DIN‑rail mounting and fast web‑based configuration, making it ideal for large‑scale field deployments.
The best option for each scenario: DC (9-48VDC), AC (110-240 VAC using external power adapter included).
Description
Imber Smart family is designed to provide secure, robust and flexible IP connectivity in industrial and Smart City deployments, enabling the integration of devices, sensors and automation systems in remote locations. Its architecture combines mobile, Wi‑Fi and Ethernet communications, ensuring reliable access for OT and IT applications and supporting the modernization and connectivity of distributed infrastructures.
Its compact, industrial and rugged design, with extended temperature operation, ensures continuous 24x7 performance in unattended environments and demanding conditions.
The device incorporates SCADA protocols such as Modbus and IEC‑101/104 gateways, as well as Serial‑IP and digital I/O, allowing direct connection to RTUs, meters, sensors and control devices without additional equipment. This versatility makes it suitable for industrial automation, distributed telemetry, smart lighting or municipal control systems.
In addition, Imber 5G offers multiple security mechanisms and corporate VPNs (IPSec, OpenVPN, GRE, DMVPN), providing encrypted communications suitable for critical infrastructures. Its remote management capabilities through Cloud Net Manager enable supervision of large device fleets, mass configuration and reduced operational and maintenance workloads, simplifying the entire deployment lifecycle.
Imber 5G features 4 Fast Ethernet ports 10/100/1000 BASE-T with RJ45 connectors. One of them is configurable as LAN/WAN interface.
Imber 5G features serial RS‑232 and RS‑485 interfaces with support for SCADA protocols. It also includes 2 digital inputs for triggering alarm events and 2 digital outputs for controlling slave devices.
Data from the serial port can be transparently encapsulated over IP. The "IEC-101 to IEC-104 gateway" function also allows IEC-101 RTUs to be maintained and central management software to migrate to IEC-104.
Imber 5G housing is designed for optimal heat dissipation, guaranteeing operation between -30ºC and 70ºC with up to 95% humidity. It can be mounted on a DIN rail or wall.
Standard mouting for industrial installations.
Embedded 3G/4G/5G interface with a dual SIM card tray for automatic backups. Advanced Teldat system for proactive monitoring and automatic recovery from WWAN incidents.
Imber 5G supports 2,4G and 5,8G Wi-Fi bands and it can operate in either Access Point mode or Client mode.
It offers advanced encrypted connectivity to ensure the integrity and protection of critical industrial and SCADA infrastructures.
Imber 5G features an input voltage range from 9 to 48 VDC. It also includes by default an external AC/DC 100-240V power adapter.
Imber 5G supports centralized remote management through Teldat Cloud Net Manager, simplifying large‑scale deployments, accelerating field supervision, and reducing operational costs.
Download the product datasheet →
